KL-T8720-2023HM Pocket Hemming Unit（Brother T8720C)/KL-MH380-2023HM Pocket Hemming Unit(JUKI MH380)

KL-T8720-2023HM/KL-MH380-2023HM

Quantity:

Contact Now

add to cart

Description:

1.KL-T8720-2023HM:Lock stitch;KL-MH380-2023HM:Chainstitch;

2.Sewing heads are driven by Hohsing direct drive;

3.Stepper motor controlled belt-feeding system, synchronous with the sewing head;

4.Stepper motor feeding assure no waves, curves or wrinkleless;

5.Flexible Transferring Wheel Adapting to Verities of Fabric Thickness Changes；

6.Thread trimming over sensor by cutter knife, 1 or 2 cuts depending the pocket distance；

7.Brother lockstitch with large capacity rotary hook；

8.Thread end, or thread break monitor;

9.Flexible Hemming Width Setting Mechanism；

10.Auto-Stacker, Auto-Cutter；

Application:

Efficiency:

Production : 500-800pcs/hour

Specification：

Machine Model	KL-T8720-2023HM/KL-MH380-2023HM
Machine Head Model	BROTHER:T8720C-05 JUKI:MH380
Maxmum Sewing Speed	BR:3000Rpm JK:5000Rpm
Needle Type	BR:DP5 JK:TV7
Needle Gauge	1/8;3/16;5/16;3/8;1/2
Available Folders	8-12mm;12-15mm;15-18mm
Shuttle Type	Vertical half rotate 2 times capaticy
Thread Breakage Detection	Equipped
Motor	750W
Voltage	220V-240V Mono 50/60Hz
Air Pressure/Air Consumption	0.5MPa 3L/min
Machine NW	176KG
Machien GW	230KG
Machine Size	12259501300mm
Package Size	131011101495mm
