KL-7300A-COIN Coin Pocket Setter Machine(Brother S-7300A)
KL-7300A-COIN
Automatic machine for making coin pockets
Quantity:
Description:
1.Brother S 7300A sewing head, smooth & stable stitch guaranteed;
2.Easy moulds changing in only 15 minutes;
3.Cold-folding mechanism to maximumly improve efficiency;
4.Equipped with thread breakage detector;
5.Pocket folding / attaching / stacking in one operation for all kinds of fabrics,including stretch;
6.Big capacity rotary hook;
7.Laser indicators for correct positioning of the garment;
8.Data can be quickly transferred between different machines by USB;
Application:
Apply to Medium & Heavy Weight Fabric
Specification:
| Machine Model | KL-7300A-COIN |
| Sewing Head | Brother S 7300A |
| Needles | DB*1 |
| Max Sewing Speed | 3500Rpm;Adviced 3000Rpm |
| Stitch length | 1-6mm |
| Size of pockets | Min:60*60mm;Max:120*120mm |
| Stitching field | X-Y:170*160mm |
| Productivity | 320 pockets or pocket facings/H |
| Voltage | 220V-240V Monno 50/60Hz |
| Power | 0.52Kw |
| Air pressure/Consumption | 5.5Bar/65L/min |
| Dimensions mm L*W*H | 1600*1400*1300 |
| Weight(NW) | 269Kg |
| Dimensions mm Packed L*W*H | 1320*1520*1490 |
| Weight(GW) | 342Kg |
Video:
